R911311945 (CSH01.1C-PB-EN1-NNN-MA1-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN1-NNN-MA1-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911311945 (CSH01.1C-PB-EN1-NNN-MA1-NN-S-NN-FW) serves as a digital control section for IndraDrive controllers. It is designed for single-axis applications and mounts on a power section, receiving DC supply for itself and any optional modules. This unit features three slots for optional modules and a dedicated slot for a safety module. Slot 1 supports an encoder HSF/RSF module compatible with MHD and MKD motors at 18.2 V AC (peak-to-peak) or 8 V DC. Slot 3 houses an analog I/O extension module, providing two analog outputs. The R911311945 uses PROFIBUS as its master communication interface. Identification is via type plates indicating type code and serial number.

Technical Specifications

Product Type
Digital Control Section

Category
IndraDrive Controller

Use
Single axis applications

Slots for optional plug in modules
3

Safety Module Slot
1

Encoder Module Type
HSF / RSF

Encoder module operation
18.2 Volts AC peak-to-peak or 8 Volts DC

Compatible Motors
MHD and MKD motors

Slot3
Analog I/O extension module

Available slot for Optional modules
2

Control panel compatibility
Standard control panel

Hot-Swap
Not supported

Master communication interface
Profibus

Identification
Type plate (include type code and serial number)

Firmware identification
Separate type plate

Installation
By trained professionals.
