R911312297 (CSH01.1C-PB-ENS-EN2-EN2-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-ENS-EN2-EN2-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911312297 (CSH01.1C-PB-ENS-EN2-EN2-S1-S-NN-FW) is a CSH01.1 control section intended for industrial automation tasks including printing, packaging, robotics, hoists, conveyors, and handling or food processing machinery. It features two analog outputs and supports master communication via PROFIBUS. Encoder compatibility includes Indradyn, Hiperface, 1 Vpp, and TTL (S1, M1, S2, and M2 types). Dimensions are 241 mm x 103 mm x 49.5 mm. The device requires a +24V and 0V power supply for digital inputs at terminals X31.8 and X31.9. Design measures allow for operation in standard industrial environments; protection from pollutants, metallic chips, and oily substances is necessary. Active heat dissipation through forced ventilation is recommended. Firmware is supplied separately, and all installation should follow product manual specifications.

Technical Specifications

Application Type
Industrial Automation

Design
Standard

Heat Dissipation
Can be cooled through forced ventilation

Firmware
Not included, to be ordered separately

Encoder Support
S1, M1, S2, M2

Dimensions
241mm (height) x 103mm (width) x 49.5mm (depth)

Power Supply
+24V, 0V for digital input devices

Power Connection Points
X31.8 and X31.9

Control Functionality
Advanced-level

Included in Package
Product manual for installation instructions.
