R911312311 (CSH01.1C-SE-EN2-NNN-MD2-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN2-NNN-MD2-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911312311 (CSH01.1C-SE-EN2-NNN-MD2-NN-S-NN-FW) is a control section for electric drive controllers, featuring two analog outputs, SERCOS interface for master communication, and support for EnDat 2.1/1 Vpp/TTL primary encoders. It incorporates digitally isolated inputs and outputs and stores parameters, operating data, and firmware on a PFM02.1 multimedia card. Physical mounting of the section is limited to 20 cycles. Cabinet connection is achieved via an RKS0004 cable at point X17, with a maximum cable length of 10 meters. This model requires 8AWG grounding and includes protective guards and covers. Installation, usage, and maintenance are to conform to EMC guidelines and should only be performed by qualified personnel. Safety functions are provided to prevent unintended startups and overheating.

Technical Specifications

Mounting/Dismounting Limit
20 times

Connection to Terminal Strip
Through RKS004 cable not longer than 10m

Intended use
Original state

Function
Controls and monitors electric motor working

Applications
Handling and mounting systems

Component Category
C3

Device Handling
By skilled personnel

Installation Requirements
Compliance with EMC requirements

Grounding Connection
Copper wire, minimum 8AWG cross-section

Unintended Startup Prevention
Isolation of drive power connection

Restrictions
Functioning not allowed near radio equipment

Handling Requirements
Use of suitable tools and equipment.
