R911313876 (CSH01.1C-PB-EN2-NNN-MD2-NN-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The R911313876 (CSH01.1C-PB-EN2-NNN-MD2-NN-S-NN-FW) is a CSH01.1C control section within the Bosch Rexroth ADVANCED IndraDrive series, designed for integration into automated motion systems. This model features a PROFIBUS master communication interface for control system connectivity and supports primary encoder options including EnDat 2.1, 1 Vpp, and TTL signal types. It incorporates two analog outputs, digital I/O extension, and SSI encoder evaluation. Electrical connections utilize spring terminals and screw terminal blocks. The unit is classified under category C3 in accordance with IEC 61800-3 and necessitates appropriate radio interference suppression. Peak inrush current is rated at 4 A with a maximum pulse width of 100 ms.

Technical Specifications

Interface
PROFIBUS

Encoder Evaluation Interface
5V supply voltage

Connection Points
Spring terminals and screw terminal blocks

Typical Inrush Current
4A

Maximum Pulse Width
100ms

Extension Interfaces
Digital I/O extension, SSI encoder evaluation

Supply Voltage Groups
Separate for each input and output group

Compliance
IEC 61800-3 category C3
