R911313879 (CSH01.1C-SE-ENS-EN1-MEM-NN-S-NN-FW)

CSH Advanced Controllers

  In Stock, Ships Fast
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The Bosch R911313879 (CSH01.1C-SE-ENS-EN1-MEM-NN-S-NN-FW) is a modular control section designed for integration with IndraDrive controllers in single-axis configurations. Typical application areas include machine tools, paper processing, food machinery, and assembly systems. The unit is equipped with a SERCOS master communication module that supports high-speed serial communication, and it provides two analog outputs. The primary encoder interface supports Indradyn, Hiperface, 1 Vpp, and TTL encoder signals. This control section does not feature an integrated safety module but allows for operator inputs and supports up to five selectable safety functions. On-board emulation of both incremental and absolute encoder signals is available. The unit is compatible with a standard control panel featuring a single-line display, but it is not hot-plug compatible; the panel must be connected or disconnected only when the device is powered down. Specification and configuration details can be confirmed on the product type plate.

Technical Specifications

Type
modular control section

Use
Motor control applications

Communication Module
SERCOS

Safety Module
Not included

Encoder Emulation Module
Included

Power Required
No Separate power required

Control Panel Compatibility
Standard control panel with a single-line display

Hot Plug Support
Not Supported

Type Plates
Attached for identification
