R911314009 (CSH01.1C-CO-EN1-NNN-NNN-S1-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The Bosch Rexroth MPN R911314009 (CSH01.1C-CO-EN1-NNN-NNN-S1-S-NN-FW) is a control section designed for IndraDrive drive controllers, supporting integration into industrial automation systems. It offers configurable switching frequencies of 2, 4, 8, 12, or 16 kHz, and supports rapid control loop execution, with velocity control cycle times between 125 and 250 microseconds and a SERCOS control cycle of 250 microseconds. This MPN provides a single analog input and two analog outputs. Master communication is facilitated via CANopen or DeviceNet. Primary encoder interfacing options include HSF and RSF. Compatibility includes plugin modules for extended communication and encoder evaluation tasks.

Technical Specifications

Use
Installed in IndraDrive drive controllers

Switching Frequencies
2 kHz, 4 kHz, 8 kHz, 12 kHz, 16 kHz

Analog Inputs
1

Velocity control time
125 to 250 µs

Sercos control time
250 µs

Position control cycle time
Short

Current control cycle time
Short

Plug-and-Play
Yes
