R911315251 (CSH01.1C-SE-EN2-EN1-MA1-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN2-EN1-MA1-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911315251 (CSH01.1C-SE-EN2-EN1-MA1-S1-S-NN-FW) is an industrial controller unit designed for integration into automation systems requiring high-speed and precise control. It supports seven to eleven digital inputs, two analog outputs, one analog input, and four digital outputs. The device includes a serial RS232 interface, master communication via SERCOS Interface, and a primary encoder option compatible with EnDat 2.1, 1 Vpp, and TTL. It provides an S1 safety function and features a cycle time as low as 250 microseconds, allowing modification of speed, current, and position in real time. Wiring must conform to 0.75 – 1.50 mm twisted pair cable, and operation requires a 24 V input voltage. The control unit's dimensions are 49.5 mm (depth), 103 mm (width), and 244 mm (height). Suitable for applications in printing, packaging, and food processing automation environments.

Technical Specifications

Digital Inputs
7-11

Interface
Serial RS232

Connecting Module
SERCOS Interface

Safety Option
S1 (Safety Technology I/O)

Analog Inputs
1

Digital Outputs
4

Maximum Mount/Unmount Times
20

SERCOS Cycle Time
Minimum 250 microseconds

X4 Slot
EnDat2.1 Encoder, Power Consumption - 6W

Control Panel
Intuitive

Firmware
Configurable (Ordered Separately)

Wire Coupling
0.75 - 1.50 mm Twisted Wire

Input Voltage
24V

Temperature Range
As per Specifications

Dimensions
49.5 mm Depth, 103 mm Breadth, 244 mm Height

X8 Slot
HSF/RSF Encoder

X10 Slot
Analog I/O Extension
