R911315501 (CSH01.1C-S3-EN1-EN2-NNN-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-S3-EN1-EN2-NNN-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911315501 (CSH01.1C-S3-EN1-EN2-NNN-NN-S-NN-FW) is a control section designed for drive controllers, featuring an integrated HSF/RSF encoder in slot X4 and an EnDat2.1 encoder in slot X8. It is equipped with one analog input, two analog outputs, four digital outputs, RS232 serial interface, and accommodates seven to eleven digital inputs, including two touch probes. The device supports a SERCOS III master communication module and operates with speed, position, and current control cycles selectable between 62.5 and 500 microseconds. Pulse width and frequency settings are configurable from 2 to 16 kHz and up to 100 ms. The unit's power consumption is 7.5 W, and its dimensions are 103 mm x 241 mm x 49.5 mm. A SERCOS cycle time of 250 ms is supported. Designed for professional use with compliant machinery, it is not intended for residential low-voltage distribution systems and may require measures for radio interference mitigation.

Technical Specifications

Encoder in X4 Slot
HSF/RSF

Encoder in X8 Slot
EnDat2.1

Analog Input
1

RS232 serial interface
1

Digital Outputs
4

Current Control Duration
62.5 to 125 microseconds

Position Control Duration
250 to 500 microseconds

Speed Control Duration
125 to 250 microseconds

Power Consumption
7.5 watts

Digital Inputs
7 to 11

Pulse Width
100 ms

Inrush Current
4 amps

Communication Module
Master SERCOS 3

Relay Output
1

Control Panel
1 watt

Dimensions (W x H x D)
103 mm x 241 mm x 49.5 mm

SERCOS Cycle Time
250 milliseconds
