R911315666 (CSH01.1C-NN-EN2-NNN-MA1-L1-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 55 Seconds

The R911315666 (CSH01.1C-NN-EN2-NNN-MA1-L1-S-NN-FW) is a industrial control device from Rexroth Indramat designed for use in automation and servo drive systems. This model provides two analog outputs and is not equipped with master communication. The primary encoder option supported is EnDat 2.1/1 Vpp/TTL. User interface is implemented via a single-line display and four pressure-sensitive keys on the control panel. Firmware is not pre-installed and must be sourced separately. The unit incorporates a multimedia card for storage of configuration and operational data, and is constructed without hazardous substances such as silicon, asbestos, or chlorinated hydrocarbons.

Technical Specifications

Device Type
Industrial Control Device

Power Section Connection
Required

Control Panel
Standard

Display Unit
One-line

Pressure-sensitive Keys
Four

Firmware Module
Not Supplied

Multimedia Card
Included

Recyclability
High Metal Content
