R911315667 (CSH01.1C-PB-EN1-NNN-MA1-L1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN1-NNN-MA1-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911315667 (CSH01.1C-PB-EN1-NNN-MA1-L1-S-NN-FW) is a control section for IndraDrive controllers, designed for manual installation onto a separately sourced power section. It features four slots: three populated with an HSF/RSF primary encoder module, an analog I/O extension (2 analog outputs), and a safety module with safety lockout support; one slot remains vacant. Communication interfaces include PROFIBUS (master) and RS-232. The unit operates within an ambient temperature of 0 to 40°C and at altitudes below 1000 meters, with switchable frequency settings from 2 to 16 kHz. Installation and operation require trained personnel. Firmware must be provided separately.

Technical Specifications

Component Type
Control Section

Part of
IndraDrive controllers

Mounting Position
Vertical

Dimensions in mm
241 x 49.5 x 103

Occupied Slots
Three

Vacancy Slots
One

Cooling Method
Convection

Required Ambient Temperature in Celsius
0 to 40

Installation Site Altitude
Does not exceed 1000 meters

Configurability
Yes

Communication Interface
Profibus, integrated RS-232 serial interface

Switching Frequencies
2 to 16 kilohertz

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the CSH01.1C-PB-EN1-NNN-MA1-L1-S-NN-FW.

Exchange

Want to sell your CSH01.1C-PB-EN1-NNN-MA1-L1-S-NN-FW?
