R911315668 (CSH01.1C-PB-EN2-MEM-MA1-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-MEM-MA1-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911315668 (CSH01.1C-PB-EN2-MEM-MA1-S1-S-NN-FW) is a modular control section designed for use in IndraDrive drive systems, featuring a 9-pin female connection interface suitable for wire sizes between 0.25 and 0.5 mm2. This unit integrates an EnDat 2.1 encoder module compatible with 5V sin-cos or square-wave encoders and provides encoder emulation for both absolute and incremental signals. It includes a safety module that enables drive interlock, standstill, direction control, and regulated speed—these functions require encoder feedback. The primary master communication is over PROFIBUS, while an analog I/O extension module provides two analog outputs. The unit measures 241 x 49.5 x 103 mm, supports vertical mounting, and operates with a power consumption of 7.5 W. Adaptation to specific application requirements is achieved through firmware and modular hardware extensions.

Technical Specifications

Safety Module
Yes

Connection for safety module
9-pin female interface

Connection Wire Cross-Section
0.25 to 0.5 mm2

Encoder Module
EnDat 2.1

Encoder Operation Voltage
5 Volts

Master Communication Interface
Profibus

Analog I/O Extension Module
Yes

Modularity
Yes

Software Adaptation
Yes

Firmware
Ordered Separately

Number of Slots
Varies

Compatible Control Panel
Standard

Dimensions
241 x 49.5 x 103 millimeters

Mounting Orientation
Vertical

Power Consumption
7.5 Watts.
