R911316313 (CSH01.1C-S3-EN2-ENS-NNN-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-S3-EN2-ENS-NNN-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911316313 (CSH01.1C-S3-EN2-ENS-NNN-S1-S-NN-FW) is a Bosch Rexroth drive controller featuring the CSH01.1 control section. It utilizes SERCOS III as the master communication interface and supports EnDat 2.1, 1 Vpp, and TTL encoder options. The device provides 2 analog outputs and includes both digital and analog I/O ports. Designed with IP20 protection, it offers resistance to dust and solid objects but must be shielded from water and coolants. The controller operates with natural convection cooling; supplemental fan cooling is recommended in confined installations. An external supply voltage is required at X31.8 and X31.9, supported by a protective diode for reverse polarity protection. The integrated operating panel features a single-line display for status readings. Installation should occur in areas with minimal heat and electromagnetic interference.

Technical Specifications

Product Type
Drive Controller

Communication Interface
SERCOS III

Protection Category
IP20

Cooling Method
Natural Convection

Communication Support
Multi-Ethernet

Digital I/O Ports
Yes

Analog I/O Ports
Yes

Operating Panel
Standard with Single-line Display

Signal Source Impedance
Low

Dedicated Connection Point
X2 for Serial Interface Only

Minimum Repair Time
1-2 Weeks
