R911316584 (CSH01.1C-PB-ENS-MA1-MD2-S1-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 36 Seconds

The R911316584 (CSH01.1C-PB-ENS-MA1-MD2-S1-S-NN-FW) is a Bosch Rexroth IndraDrive CSH01 ADVANCED control section, Version 1, designed for single-axis drive control within industrial automation systems. It incorporates a PROFIBUS interface for cyclical data exchange and features two analog outputs. The unit supports encoder systems including IndraDyn, Hiperface, 1 Vpp, and TTL, with options for sin-cos or EnDat 2.1 interface at 12V, and 5V-TTL square-wave types. The device is specified as IEC 61800-3 category C3, requiring external radio interference suppression. The front panel includes a single-line display providing operational status and diagnostic information. Firmware must be sourced separately.

Technical Specifications

Product
Bosch Rexroth IndraDrive System

Type
Configurable Version 1

Bus System
PROFIBUS

Supply Voltage
12V

Encoder Interface
Standard Encoder Evaluation Interface

Firmware
Ordered separately

Category
C3 (IEC 61800-3)

Display
Standard single-line

Hot-plug
Not Suitable.
