R911316857 (CSH01.1C-CO-EN2-NNN-NNN-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-CO-EN2-NNN-NNN-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911316857 (CSH01.1C-CO-EN2-NNN-NNN-S1-S-NN-FW) is a control section for IndraDrive drives, typically pre-assembled with the power section or available for separate installation. It supports a maximum of 20 mounting and dismounting operations and integrates a CANopen/DeviceNet master communication interface, two analog outputs, and default control panel capability. The unit is designed with safety technology I/O compatibility and supports encoders with the EnDat 2.1, 1 Vpp, and TTL interfaces. The control section includes an RS-232 interface for programming and diagnostics. Supported control cycle times are 62.5 microseconds and 125 microseconds, with switching frequencies from 2 to 16 kHz. The device is marked for identification and ordering with a type plate. Usage and maintenance should be performed by qualified personnel.

Technical Specifications

Product Type
Control Section for IndraDrive drives

Components
Control and Power Section

Installation
Should be installed by trained personnel

Configurability
Yes

Master communication Interface
CANopen/DeviceNet

Control Panel
Standard

Firmware
Ordered separately

Safety Technology I/O
Supported

Encoder Interface
EnDat 2.1

Type Plate Information
Type, Part Number, Serial Number, and Bar Code

RS-232 Serial Interface
Available

Current Control Cycle Times
62.5 microseconds and 125 microseconds

Switching Frequencies
2 to 16 kilohertz

Maintenance
Should only be performed by trained personnel
