R911316860 (CSH01.1C-PB-ENS-EN2-MD2-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-ENS-EN2-MD2-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch R911316860 (MPN: CSH01.1C-PB-ENS-EN2-MD2-NN-S-NN-FW) is a digital CSH-series control unit engineered for single-axis positioning within IndraDrive assemblies. Operating from a 24 VDC input and consuming 7.5 W, the device tolerates ambient temperatures from 0 to 40 °C and elevations up to 1000 m, with an inrush current of 4 A (max pulse width 100 ms). The modular structure includes four slots: three populated with an IndraDyn encoder module, a digital I/O extension (SSI interface), and an EnDat 2.1 encoder module, while the fourth is reserved for an optional safety module. Supported features include two analog outputs, PROFIBUS master communication, and primary encoder compatibility with IndraDyn, Hiperface, 1 Vpp, and TTL. ESD precautions must be observed during handling.

Technical Specifications

Type
Digital Control Unit

Use
Single-axis positioning applications

Mounts On
Power Section

Deployment
Motor control

Cooling Type
Convection

Ambient Temperature
0 to 40 degrees Celsius

Altitude
0 to 1000 meters

Input Voltage Rating
24 Volts DC

Power Consumption
7.5 Watts

Inrush Current
4 Amps

Maximum Pulse Width
100 milliseconds

Architecture
Modular

Slots
4

Reserved Slot
Safety module (empty)

Communication Module
Profibus

Configurable
Yes

Compatibility
Standard Control Panel

ESD Precaution
Required

Discharge
Grounding
