R911317239 (CSH01.1C-CO-NNN-NNN-NNN-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-CO-NNN-NNN-NNN-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911317239 (CSH01.1C-CO-NNN-NNN-NNN-NN-S-NN-FW) is a control section designed for use with IndraDrive controllers, featuring CANopen/DeviceNet master communication and two analog outputs. It is equipped with four front-panel module slots, with one dedicated to safety functions including safe torque off, safe motion, starting lockout, and safety technology I/O. The remaining slots accommodate additional modules as needed. A memory card slot and control interfaces are positioned on the front panel. The device supports integration with a standard control panel for recognition prior to startup. It measures 241 mm in height, 103 mm in depth, and 49.5 mm in width. Proper safety instructions must be followed during installation and operation by qualified personnel. Firmware is not included and must be sourced separately.

Technical Specifications

Use
Component of IndraDrive controllers

Max Mounting Cycles
20 times

Slots for Optional Modules
4 (1 safety, 3 customizable)

Control Panel
Standard, Must be plugged in before power on

Firmware
Ordered separately

Master Communication
DeviceNet/CANopen

Dimensions
Height: 241mm, Depth: 103mm, Width: 49.5mm

Operation
Requires trained personnel

Safety
Follow instructions in documentation

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the CSH01.1C-CO-NNN-NNN-NNN-NN-S-NN-FW.

Exchange

Want to sell your CSH01.1C-CO-NNN-NNN-NNN-NN-S-NN-FW?
