The R911317755 (CSH01.1C-NN-EN2-MEM-MA1-NN-S-NN-FW) is a Bosch Rexroth CSH01.1 series single-axis control unit designed for standard control panel operation. This unit is equipped with a RS 232 serial interface, supports 7 to 11 digital inputs, 0 to 4 digital outputs, 1 analog input, and 2 analog outputs. It does not include master communication or safety technology. Operational switching frequency ranges from 2 to 16 kHz. Optional modules include Encoder EnDat 2.1/5 Vpp/TTL, Encoder Emulator, and Analog Input/Output extension. Power consumption is rated at 7.5 W (no plugins), with a 4 A inrush current. Connection is by screw terminal blocks and spring terminals. Peak pulse width is 100 ms; standard control panel, EnDat2.1/1 Vpp/5 V TTL, and encoder emulator modules consume 1 W, 6 W, and 2 W, respectively.

Technical Specifications

Product Category
CSH01.1

Design Type
Type-1

Configurable
Yes

Master Communication Interface
No

Safety Technology Option
No

Control Panel Type
Standard

Interface
RS 232 serial

Digital Inputs
7-11

Digital Outputs
0-4

Analog Inputs
1

Analog Outputs
2

Permissible Switching Frequencies
2, 4, 8, 12, 16 kHz

Power Consumption without plugins
7.5 Watts

Inrush Current Rating
4 Amperes

Peak Pulse Width
100 ms

Analog I/O Extension Power Consumption
2 Watts

Standard Control Panel Power Consumption
1 Watt

EnDat2.1 Power Consumption
6 Watts

Encoder Emulator Power Consumption
2 Watts

Connection Points Type
Screw terminal blocks and spring terminals.
