R911318766 (CSH01.1C-CO-EN2-EN2-NNN-L1-S-NN-FW)

Name: R911318766 (CSH01.1C-CO-EN2-EN2-NNN-L1-S-NN-FW)
Brand: Indramat Controls
SKU: CSH01.1C-CO-EN2-EN2-NNN-L1-S-NN-FW
Price: 920.00 USD
Availability: InStock

CSH Advanced Controllers

Front Left

Available, Ships in 1-2 weeks

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth CSH01.1 Drive Controller, MPN R911318766 (CSH01.1C-CO-EN2-EN2-NNN-L1-S-NN-FW), is part of the advanced CSH series designed for industrial automation. It supports two analog outputs and is equipped with master communication interfaces for CANopen and DeviceNet, selectable via switch. The controller provides two encoder ports (X4, X8) supporting EnDat 2.1, 1 Vpp, or TTL encoder options. A starting lockout is integrated for safety, and operating parameters are accessible via the standard control panel. Installation must be in a dry, well-ventilated environment. Firmware for this unit is ordered separately.
