R911318771 (CSH01.1C-PB-EN2-MEM-MA1-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-MEM-MA1-NN-S-NN-FW Series Image

In Stock, Ships Fast

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911318771 (CSH01.1C-PB-EN2-MEM-MA1-NN-S-NN-FW) is a digital control unit designed for integration with a power section that supplies 24V DC and has a typical power consumption of 7.5W. This unit is equipped with an analog I/O extension module offering four additional channels operating at ±10V DC, and includes an encoder emulation module capable of replicating both incremental and absolute value signals. An EnDat 2.1 module is also installed for encoder feedback. The unit does not contain a safety module but is compatible with four options from the CSH series. Communication is facilitated via a 9-pin D-sub female PROFIBUS interface, with recommended connection using stranded copper wire of cross-sectional area 0.08 to 0.5 mm². The device provides two analog outputs and supports EnDat 2.1, 1 Vpp, and TTL as primary encoder options. Installation should be performed by qualified personnel.

Technical Specifications

Product Type
Digital Control Section

Mount Type
Power Section

Power Supply
24 Volts DC

Power Consumption
Approximately 7.5 Watts

Typical Shipping
Part of IndraDrive Drive Controller

Mounting
Manual by Trained Technical Personnel

Remount Limit
20 Times

Analog I/O Extension Module
Four Channels at ±10V DC

Signal Isolation
Galvanic

External Power Supply Requirement
Not Required for Encoder Emulation Module

Encoder EnDat 2.1 Module
Installed

Safety Module
Not Included, Can Support Four Different Modules

Control Panel Compatibility
Standard only

Communication Interface
Profibus with 9-Pin D-Sub Female Interface

Installation
Only by Qualified Personnel.
