R911318777 (CSH01.1C-SE-EN2-NNN-MD2-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN2-NNN-MD2-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911318777 (CSH01.1C-SE-EN2-NNN-MD2-S1-S-NN-FW) is a control section featuring Safety Technology I/O and four groups of digital outputs, each with four channels and independent supply voltages. It supports programming via a preformatted memory card. The unit incorporates a Type 2 relay with a 10 ms delay and SSI encoder evaluation for position detection. It provides two analog inputs rated at ±10 V with a typical resistance of 160 kOhms, and two analog outputs featuring short circuit and overload protection. Communication is supported through an RS 232 interface (9.6 kBaud to 115 kBaud) and a SERCOS master interface, with primary encoder options including EnDat 2.1, 1 Vpp, and TTL. The device connects via screw terminal blocks using wire ends with ferrules and is designed for up to 20 mounting cycles. It should be stored or transported in conductive packaging.

Technical Specifications

Safety Technology
I/O safety option

Digital Output Groups
4

Digital Outputs per Group
4

Voltage for Digital Groups
Separate supply

Memory
Preformatted memory card

Type 2 Relay Pickup Delay
10ms

Type 2 Relay Drop-Out Delay
10ms

Encoder Evaluation
SSI interface

Analog Inputs
2

Voltage Rating of Analog Inputs
+/-10V

Resistance of Analog Inputs
160 kOhms

RS 232 Interface
1 node

Transmission Rate
Between 9.6kBaud and 115kBaud

Analog Outputs
Type 2 with short circuit and overload protection

Error Memory Diagnosis
With control panel

Adapter
Universal adapter for safety technology

Mounting and Dismounting Limit
20 times

Ground Connection
Required

Packaging
Conductive

Velocity Control Times
250µs, 500µs

Position Control Times
125µs, 250µs

Shipping
Worldwide
