R911319201 (CSH01.1C-PB-EN1-MA1-MD2-L1-S-NN-FW)

Name: CSH01.1C-PB-EN1-MA1-MD2-L1-S-NN-FW
Brand: Indramat Controls
Price: 153 USD
Availability: InStock

CSH Advanced Controllers

CSH01.1C-PB-EN1-MA1-MD2-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911319201 (CSH01.1C-PB-EN1-MA1-MD2-L1-S-NN-FW) is a Bosch Rexroth single-axis drive controller designed for use in automation systems such as machine tools, printing, food processing, and packaging equipment. The control section provides configurable motion functions including velocity, current, and position control, subject to firmware configuration. It features a standard control panel, a PROFIBUS master communication interface, an analog extension with 2 analog outputs, and an HSF/RSF encoder interface. L1 safety technology is integrated. Dimensions are 103 mm × 49.5 mm × 241 mm, with a 24V input. The controller is compatible with firmware versions FWA-INDRV*-MPx-18VRS and later; firmware is not included.

Technical Specifications

Product Type
Single-Axis Drive Controller

Installation Requirement
Licensed Engineer or Service Worker

Install/Discount Limit
20 Times

Digital Inputs
7-11

Additional Slots
2

Velocity Control Cycle Time
125-250

Current Control Cycle Time
62.5-125

Position Control Cycle Time
250-500

SERCOS Cycle Time
250 Minimum

Control Panel
Standard

Communication Module
PROFIBUS Master

Physical Dimensions
103mm x 49.5mm x 241mm

Supported Firmware
FWA-INDRV*-MPx-18VRS or above

Analog Inputs
1

Analog Outputs
2

Wire Diameter
0.75-1.50mm

Voltage Input
24V

Firmware
Sold Separately
