R911319452 (CSH01.1C-PB-EN1-NNN-MD2-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN1-NNN-MD2-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911319452 (CSH01.1C-PB-EN1-NNN-MD2-S1-S-NN-FW) is a Bosch Rexroth CSH01 series control section intended for single-axis drive operations within the IndraDrive drive system. It is equipped with a standard encoder interface supplying 12V and supports HSF/RSF as the primary encoder option. The unit enables communication via PROFIBUS and offers a digital I/O extension with 16 inputs and 16 outputs. Additionally, it provides two analog outputs, an SSI interface for absolute position detection, and safety technology I/O for safety-relevant functions. The device is designed for integration with PELV systems using basic insulation and is not recommended for installation or removal more than twenty times.

Technical Specifications

Product Type
Control Section of IndraDrive Drive System

Control Type
Advanced Control Section

Suitability
Single-Axis Drive Operations

Encoder Interface
Standard

Supply Voltage
12V

Suitable Area of Application
Industrial use, Not for Household Areas

Communication Technology
PROFIBUS Interface

Digital I/O Extension
16 Inputs and 16 Outputs

SSI Interface
Available

Safety Technology I/O
Available

Recommended Mounting and Dismounting Limit
20 times.
