R911319914 (CSH01.1C-NN-EN1-MA1-MD2-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-NN-EN1-MA1-MD2-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth control section, MPN R911319914 (CSH01.1C-NN-EN1-MA1-MD2-S1-S-NN-FW), is designed for integration with drive controllers in single-axis applications within industrial environments. This CSH series module measures 241 x 103 x 49.5 mm and includes its own type plate. It incorporates two analog outputs, a Normally Open relay contact, multiple digital inputs and outputs, and supports primary encoder options HSF/RSF. The unit is not equipped with a master communication interface and features one slot for safety technology configuration. Installation and removal require precautions against electrostatic discharge and should be performed by qualified personnel only.

Technical Specifications

Configuration
Configurable with one axis

Product Group
CSH

Configuration Slot
One with safety technology

Size
241 x 103 x 49.5 mm

Type Plate
Individual for each component

Mounting requirement
Authorized or trained personnel only

Risk factor
Susceptible to electrostatic charge

Usage
Industrial environments

Relay Contact
1 Normally Open

Line code
1

Communication support
None

Control cycles
Two cycle times for velocity, position and current

Digital I/O
Multiple digital inputs and outputs

Design Code
1

Encoder module
HSF / RSF

Encoder Connectors
X4.1 female D-Sub 15 pole

Voltage supply of Encoder
11.6 volts

Maximum output current of Encoder
500mA

Sine output frequency of Encoder
4kHz

Additional Card Slot
X7 connector

Power supply protection
Protective diode

Shipping
Available for international shipping.
