R911319917 (CSH01.1C-SE-EN2-EN1-MD2-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN2-EN1-MD2-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911319917 (CSH01.1C-SE-EN2-EN1-MD2-S1-S-NN-FW) is a Bosch Rexroth CSH01.1 control section module designed for automation applications requiring precise signal management and control. It features an EnDat 2.1 encoder interface in the X4 slot, supports digital extension I/O with an SSI encoder interface in the X10 slot, and provides two analog outputs and one analog input. The module includes four digital outputs, a single relay contact capable of operating at 2–16 Hz, and an RS232 serial interface. Powered by a 24V DC supply, it supports a maximum pulse width of 100 ms with an inrush current of 4A. The unit supports velocity, position, and current control cycles, incorporates the S1 safety function, and uses the SERCOS interface as the master communication protocol.

Technical Specifications

Type
Control Section

Single Relay Contact
Yes

Switching Frequency
2 to 16 Hz

X4 Slot
EnDat2.1 Encoder

X4 Slot Power Consumption
6W

X10 Slot
Digital Extension I/O with SSI Encoder Interface

Analog Inputs
Single

RS232 Serial Interface
Yes

Digital Outputs
Four (modifiable)

Analog Outputs
Two (modifiable)

Maximum Pulse Width
100ms

Inrush Current
4A

Cycle Time Function
Yes

Velocity Control Time
125 to 250 microseconds

Current Control Time
62.5 to 125 microseconds

Position Control Time
250 to 500 microseconds

Safety Option
S1

Power Source
24-volt DC

SERCOS Interface Connection Module
Yes

X8 Slot
HSF/RSF Encoder

X8 Slot Power Requirement
6 watts

Control Panel Power Requirement
1 watt

Pre-Supply Testing
Yes

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the CSH01.1C-SE-EN2-EN1-MD2-S1-S-NN-FW.

Exchange

Want to sell your CSH01.1C-SE-EN2-EN1-MD2-S1-S-NN-FW?
