R911320073 (CSH01.1C-PB-EN2-ENS-MEM-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-ENS-MEM-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911320073 (CSH01.1C-PB-EN2-ENS-MEM-S1-S-NN-FW) is an industrial automatic control unit engineered for compact applications within demanding environments. It measures 103mm x 241mm x 49.5mm and requires operation between 0 to +40°C, with proper ventilation and IP20 protection. The unit supports advanced control functions for speed, position, and current regulation, features security integration at terminal X41, and provides two analog outputs. Communication is supported via PROFIBUS as the master protocol, and it is compatible with primary encoders including EnDat 2.1, 1 Vpp, and TTL. The controller incorporates a configured control section, power section, and an integrated control panel. The firmware is not included and must be procured separately.

Technical Specifications

Product Type
Control Section

Dimensions
103mm x 241mm x 49.5mm

Protection Degree
IP 20

Ambient Temperature
0 to +40 degree Celsius

Control Over
Speed, Current, Position Cycle Times

Safety Technology
Included at X41 Terminal

Memory Card Slot
At X7 Connection Point

Intended For
Commercial Applications

Firmware
Not included, Must Be Ordered Separately

Shipping
Worldwide

Package Includes
Product Manual, User Guide
