R911320282 (CSH01.1C-SE-NNN-MA1-MD2-L1-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The Bosch Rexroth CSH01.1C-SE-NNN-MA1-MD2-L1-S-NN-FW (MPN: R911320282) is a control section designed for industrial automation applications. It provides two analog output channels and supports two differential input channels with an optional module. The unit includes a relay contact with a maximum resistance of 1000 milliohms, as well as digital I/O extension capabilities and SSI encoder evaluation for absolute position detection. Two digital input groups and four output groups, each with separate supply voltages, are integrated. The device communicates via a SERCOS interface and is not equipped with a primary encoder module. Proper grounding is required to avoid electrostatic damage. Installation must adhere to specified ambient and application standards to ensure safe operation.

Technical Specifications

Operating Environment
Not recommended for residential localities

Electrical Safety
Adversely affected by electrostatic charges

Structural Changes
Cannot be made

Operation
Only in stated combinations of components

Ambient Conditions
Must adhere to the indicated conditions

Monitoring Function Performance
Can result in faulty movements if not effective

Clocking Frequency
According to the power section

Digital I/O Extension
Permitted

SSI Encoder Evaluation
Permitted

Digital Input Groups
Two groups with eight inputs per group

Digital Output Groups
Four groups with four outputs per group

Supply Voltage
Separate for each input and output group

Absolute Position Detection
For encoders with an SSI interface
