R911321263 (CSH01.1C-NN-ENS-EN2-MA1-L1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-NN-ENS-EN2-MA1-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911321263 (CSH01.1C-NN-ENS-EN2-MA1-L1-S-NN-FW) is a single-axis control section from the IndraDrive series by Bosch Rexroth, designed for advanced motion control applications. It features support for a range of encoder interfaces, including IndraDyn, Hiperface, EnDat 2.1, 1Vpp, and 5V TTL, with a third interface for analog I/O expansion. The unit is equipped with built-in analog and digital I/Os and offers two analog outputs. It operates within an ambient temperature range of 0 to 40 °C, allowing reduced performance up to 55 °C, and has a mains frequency tolerance of 50–60 Hz (±2%). The module utilizes the Safe Motion safety option and is not equipped with a master communication interface. Moisture and ice accumulation must be avoided for proper function.

Technical Specifications

Product Line
IndraDrive

Product Type
CSH Single-Axis Control Section

Range
ADVANCED

Encoder Interface Support
Yes

Optional Safety Technology
Yes

Safety Technology Type
Safe Motion

Control Communication
Not Equipped

First Option Encoder Interface
IndraDyn Motors, Hiperface

Second Option Interface
EnDat 2.1, 1Vpp, 5V TTL

Third Optional Interface
Analog Input/output extension

Control Panel
Standardized Operator Control

Condensation or Ice Formation Tolerance
No

Transportation Temperature
-25 to 70 degrees C

Storage Temperature
-25 to 55 degrees C

Ambient Operating Temperature
0 to 40 degrees C

Power Reduced Operating Temperature
0 to 55 degrees C

Mains Frequency
50 - 60 Hz (+/-2)
