R911321384 (CSH01.1C-PB-EN2-EN2-NNN-L1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-EN2-NNN-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911321384 (CSH01.1C-PB-EN2-EN2-NNN-L1-S-NN-FW) is a single-axis drive controller from Bosch Rexroth, designed for integration in machine tools, handling systems, and various automation applications. The CSH01.1 control section features EnDat 2.1 encoders as the primary encoder option, supports PROFIBUS for master communication, and provides two analog outputs. Additional features include four digital outputs, one relay contact, seven to eleven user-configurable digital inputs, an L1 safety option, and a standard control panel. The device measures 103 mm in width, 49.5 mm in depth, and 241 mm in height, and is capable of a minimum SERCOS cycle period of 250 microseconds.

Technical Specifications

Product Type
Single Axis Drive Controller

Encoders
EnDat2.1

Digital Outputs
4

Relay Contacts
1

Dimensions
103mm (W) x 49.5mm (D) x 241mm (H)

SERCOS Cycle Period
Minimum 250 microseconds

Safety Option
L1 (beginning lockout)

Communication Module
PROFIBUS

Digital Inputs
7-11 (User-Configurable)

Speed Adjustment Range
125-250 microseconds

Current Adjustment Range
62.5-125 microseconds

Cycle Time Function Location Adjustment Range
250-500 microseconds.
