R911322058 (CSH01.1C-SE-EN1-EN2-EN2-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN1-EN2-EN2-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 47 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Indramat motion control part R911322058 (CSH01.1C-SE-EN1-EN2-EN2-S1-S-NN-FW) is a single-axis control section from the CSH series designed for integration into various industrial automation systems including machine tools and food packaging equipment. It features a four-button control panel with a single-line display for configuration and operation. The controller uses SERCOS interface for master communication via fiber optic connection. It supports HSF/RSF encoders and provides supply voltages of DC 8V, AC 18.2V peak-peak, and 5V through dedicated interfaces. Technical operation parameters include two analog outputs, an adjustable switching frequency from 2kHz to 16kHz, typical inrush current of 4A, and a maximum pulse width of 100ms. Safety Technology I/O is integrated for application-related safety functions.

Technical Specifications

Product Type
Single-Axis Control Section

Control Panel
Standard

Display Type
Single-Line

Master Communication Module
SERCOS

Workable Encoder Voltages
DC 8V or AC 18.2V peak-peak, 5V

Safety Technology
I/O

Allowed Switching Frequencies
2kHz, 4kHz, 8kHz, 12kHz, 16kHz

Inrush Current
4A

Maximum Pulse Width
100ms
