R911322105 (CSH01.1C-PB-ENS-NNN-MD2-L1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-ENS-NNN-MD2-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911322105 (CSH01.1C-PB-ENS-NNN-MD2-L1-S-NN-FW) is a CSH01.1 series control section for single-axis applications, supporting master communication via PROFIBUS. It is designed for compatibility with multiple encoder types including IndraDyn S, Hiperface, 1 Vpp, and TTL. The module features two analog outputs, four digital outputs, and one relay contact, supporting digital I/O expansion with an SSI encoder interface. Control response times for current are 62.5 to 125 ms and for velocity are 125 to 250 ms. An LED display provides status and error indicators. The unit is enclosed in an IP20-rated housing to protect against solid objects.

Technical Specifications

Type
Single-Axis Control Section

Support
IndraDyn S, Hiperface, and TTL encoders

Connection Point X10
Designated for extension module

Connection Point X4
For standard encoder evaluation

Maintenance Feature
Starting lockout safety features at terminal X41

Operator’s Panel
Single line LED display

Relay Contacts
1

Analog Outputs
2

Digital Outputs
4

Current Control Range
62.5 to 125 ms

Velocity Control Range
125 - 250 ms

PWM Frequency
2 to 16 kHz

Connection Point X31.8 and X31.9
For external power supply

Enclosure
IP20 rated
