R911322339 (CSH01.1C-PB-EN2-EN2-MA1-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-EN2-MA1-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911322339 (CSH01.1C-PB-EN2-EN2-MA1-S1-S-NN-FW) is a CSH line modular IndraDrive controller component utilized in automation systems requiring advanced motion control. It features three pre-installed function modules, including an analog I/O extension module and two EnDat 2.1 encoder modules, enhancing system connectivity and precision. The safety module provides support for safety technology I/O. Master communication is established via PROFIBUS. The device supports two analog outputs, operates with a 24 V power supply, and has a base unit power consumption of 7.5 W. It is intended for vertical mounting and employs convection cooling.

Technical Specifications

Product Type
Control Section

Rexroth Product line
CSH

Designed For
IndraDrive controllers

Pre-Installed Modules
4 (3 function modules and 1 safety module)

Safety Module Support
safety technology I/O

Analog Channels Resolution
12 bits

Configurable Device
Yes

Control Panel compatibility
Standard

Communication Module Support
Profibus

Mounting
Vertical on a power section

Power Source
power section

Power Output
24 Volts

Power Consumption of Basic Unit
7.5 Watts

Cooling Method
Convection cooling.
