R911322340 (CSH01.1C-S3-EN1-NNN-NNN-L1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-S3-EN1-NNN-NNN-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911322340 (CSH01.1C-S3-EN1-NNN-NNN-L1-S-NN-FW) is an advanced control section designed for integration within Bosch Rexroth drive controllers, compatible with MSK series synchronous motors. The module includes a combined input/output that supports use as a safety stop switch and permits connection of two conductors to a single terminal. It provides four analog inputs, two analog outputs, and uses an eight-pole circular MiniDin female connector for serial interface. Power consumption is rated at 7.5W at 24VDC. The controller supports SERCOS III master communication and accommodates HSF/RSF encoder options. All connections utilize industry-standard Cat 5e cabling with ITP-type shielding. Handling precautions should be observed due to potentially high surface temperatures.

Technical Specifications

Material Composition
Copper, Aluminum, Steel, Synthetic materials

Input/Output Type
Combined single terminal

Power Consumption
7.5W at 24VDC

Connection Types
ITP-type shielded Cat 5e cables

Terminal Connection Type
Screw terminal block

Serial Interface
8 poles circular MiniDin female connector

Analog Inputs Type
Type 4

Memory Slot
X7 slot for multimedia card with firmware

Relay Contact Delay Times
Pick up and drop out times of 10ms

Usage
Operation of food machines

Temperature Limitation
Does not support high maximum temperature

Safety Feature
Starting lockout with Stop Category 0

Delivery Packaging
Conductive packaging.
