R911322341 (CSH01.1C-SE-EN1-MEM-MD2-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN1-MEM-MD2-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911322341 (CSH01.1C-SE-EN1-MEM-MD2-NN-S-NN-FW) is an industrial automation control section equipped with a SERCOS interface for master communication and features a standard 1-watt control panel. The unit provides four digital outputs, two analog outputs, and a single analog input. Control response times are specified at 62.5–125 μs for current control, 125–250 μs for speed control, and 250–500 μs for position control. The X4 slot includes a 6W HSF/RSF encoder, the X8 slot supports an encoder emulator, and the X10 slot has an SSI encoder with digital extension. The PWM frequency is adjustable in 2 kHz steps from 2 to 16 kHz. Firmware for the CSH01.1 control section is ordered separately.

Technical Specifications

Product Type
Control Panel

Interface Connection Module
SERCOS

Digital Outputs
4

Analog Input
1

Current control period
62.5 to 125 microseconds

Speed control period
125 to 250 microseconds

Position control period
250 to 500 microseconds

Power Consumption of Encoder in X4 slot
6 W

Contains Encoder Emulator in X8 slot
Yes

Digital Extension in X10 slot
SSI Encoder

Adjustable PWM Frequency
2 kHz to 16 kHz

Operational Temperature Range
Limited

Delivery available globally
Yes
