R911322344 (CSH01.1C-SE-EN2-EN2-MA1-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN2-EN2-MA1-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911322344 (CSH01.1C-SE-EN2-EN2-MA1-NN-S-NN-FW) is a single-axis drive controller engineered for integration in automation systems such as packaging, printing, and food processing equipment, as well as in handling and mounting applications. The device is equipped with two analog outputs, a SERCOS interface master communication module, and an EnDat 2.1/1 Vpp/TTL encoder interface. The unit supports seven to eleven programmable digital inputs and features a minimum control cycle time of 250 microseconds with adjustable velocity response times between 125 and 250 microseconds. Operation must be confined to specified environmental limits for reliable performance.

Technical Specifications

Analog Extension
Yes in X10 Slot

Firmware
Configurable

Digital Outputs in X4 Slot
Four

Relay Contact in X4 Slot
Yes

Encoder
EnDat2.1

Minimum Cycle Time for SERCOS
250 microseconds

Width
103mm

Depth
49.5mm

Height
244mm

Communication Module
SERCOS interface Master

Programmable Digital Inputs
Seven to Eleven

Velocity Adjustment
125 to 250 microseconds

Current Adjustment
62.5 to 125 microseconds

Cycle Time Function
250 to 500 microseconds
