R911322786 (CSH01.1C-S3-EN2-EN2-NNN-NN-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The R911322786 (CSH01.1C-S3-EN2-EN2-NNN-NN-S-NN-FW) is a control section designed for industrial automation systems. It measures 103 mm x 241 mm x 49.5 mm and offers an IP20 protection rating. The unit supports multiple encoder types (EnDat 2.1, 1Vpp, TTL) and provides a master communication interface via SERCOS III. It includes two analog outputs and features distinct ports for auxiliary device connectivity. An integrated display panel provides error codes and diagnostic messages. Cooling is achieved through natural convection. Firmware must be configured prior to use.

Technical Specifications

Product Type
Control Section

Dimensions
103 mm x 241 mm x 49.5 mm

Degree of Protection
IP20

Encoder Interface Support
EnDat 2.1, 1Vpp, and TTL

Communication Interface
SERCOS III

Input and Output Ports
Yes

Firmware
Not Included (separate order)

Display Panel
Standard operating panel with single-line display

Cooling Method
Natural Convection

Delivery
Via well-reputed logistics services
