The Bosch Rexroth R911323145 (CSH01.1C-S3-EN1-EN2-NNN-S1-S-NN-FW) is a control section for a single-axis drive controller featuring four digital outputs, two analog outputs, a relay contact, and seven to eleven digital inputs. It provides master communication via SERCOS III and supports an EnDat2.1 encoder in the X8 slot as well as an HSF/RSF encoder in the X4 slot. The unit integrates S1 safety motion technology and requires configurable firmware to be purchased separately. The CSH01.1 control section measures 103 mm in width, 49.5 mm in depth, and 244 mm in height, and must be operated within specified environmental conditions. Adjustment functionality includes velocity, current, and cycle time settings.

Technical Specifications

Digital Outputs
4

Relay Contact
1

Encoder X8 slot
Endat2.1

Encoder X4 slot
HSF/RSF

Safety Motion
S1 (safe technology)

Communication Network
SERCOS 3

Minimum Cycle Time
250 microseconds

Width
103mm

Depth
49.5mm

Height
244mm

Programmable Digital Inputs
7-11

Firmware Type
Configurable (Sold Separately)

Adjustable Velocity Time
125-250 microseconds

Adjustable Current Time
62.5-125 microseconds

Adjustable Cycle Time Function
250-500 microseconds

Product Availability
Global.
