R911323492 (CSH01.1C-S3-EN2-NNN-NNN-L1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-S3-EN2-NNN-NNN-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 36 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911323492 (CSH01.1C-S3-EN2-NNN-NNN-L1-S-NN-FW) is a control section module designed for industrial automation applications, supporting SERCOS III master communication and providing two analog outputs. It features one analog input, four digital outputs, and accommodates an EnDat 2.1/1 Vpp/TTL primary encoder. The module operates with a 24 V input voltage and consumes 6 W. Connection requires 0.75-1.50 mm² twisted wire, and grounding of conductive parts must be completed prior to installation. The device allows flexible cycle time adjustments for speed, current, and position control. Physical dimensions are 49.5 mm depth, 103 mm width, and 244 mm height. L1 safety is included.

Technical Specifications

Analog Input Count
1

Digital Output Count
4

Encoder Type
EnDat2.1

Control Panel Type
Standard

Linkage Cable Diameter
0.75-1.50 mm

Input Voltage
24 V

Temperature Range
Not Specified

Maximum Installation Count
20

Cycle Time Function Availability
Yes

Safety Feature Type
L1 (beginning lockout)

Digital Input Count
7-11

Serial Port Type
RS232

Dimensions
49.5 mm x 103 mm x 244 mm

Communication Module Type
SERCOS 3

Minimum Cycle Time
250 microseconds
