R911323629 (CSH01.1C-SE-ENS-EN2-MD2-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-ENS-EN2-MD2-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911323629 (CSH01.1C-SE-ENS-EN2-MD2-NN-S-NN-FW) is a control section designed for operation within a 0-40°C temperature range and provides an IP20 enclosure rating, offering protection from solid objects but not from water ingress. The unit features two analog outputs and supports master communication via a SERCOS III, Ethernet-based interface for high-speed data exchange. It is compatible with primary encoder options including IndraDyn, Hiperface, 1 Vpp, and TTL signals. The CSH01.1C control section is intended for integration with corresponding power and control modules, and firmware must be sourced separately. Installation and setup should be performed by qualified personnel according to the CSH01 user manual.

Technical Specifications

Category
Control Units

Configuration
Configurable

Mounting
On a plain surface

Use
Operating electric motors

Ambient Temperature during operation
0 to +40 degree Celsius

Installation Height
Up to 1000 meters above sea level

IP Degree
IP20

Communication Interface
SERCOS III

Firmware
Not included, has to be ordered separately

Need for Installation
Firmware and trained service technician

Usage Guidelines
As per CSH01 user manual.
