R911323812 (CSH01.1C-PB-EN2-EN1-EN2-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-EN1-EN2-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911323812 (CSH01.1C-PB-EN2-EN1-EN2-S1-S-NN-FW) is a Bosch Rexroth motion control module featuring a standard control panel, drive controllers, machine control panels, and optional EnDat 2.1 encoder interface. It includes a navigable operator console, memory card connector, and incorporates a frequency range of 2–16 kHz with width-modulated HSF/RSF encoder support. The device has power consumption of 7.5 W, current control times from 62.5 to 125 µs, position control times of 250–500 µs, and speed control times of 125–250 µs. Natural convection cooling is used. The control section provides 11 digital inputs, 2 analog outputs, one analog input, and accommodates master communication via PROFIBUS. It also features a SERCOS cycle period of 1000 µs, an RS232 serial port, primary encoder options of EnDat 2.1/1 Vpp/TTL, and S1 safety technology. Device dimensions are 103 mm width, 241 mm height, and 49.5 mm depth. Operation is permitted up to 1000 m above sea level; firmware must be supplied separately.

Technical Specifications

Product Type
Control Section

Encoder
EN1 EN2

Control Panel
Standard

Memory Card Connector
Yes

Drive Controller
Included

Frequency Range
2 - 16 kHz

Firmware
Not Included

Power Consumption
7.5 W

Current Control Times
62.5-125 microseconds

Position Control Times
250-500 microseconds

Speed Control Times
125-250 microseconds

Cooling Method
Natural Convection

Digital Inputs
11

Touch Probe Inputs
2

Inrush Current
4 amps

Communication Module
PROFIBUS master

Relay Output
1

Safety Technology
S1

Usage Altitude
Up to 1000 meters

SERCOs Cycle Period
1000 microseconds

Dimensions
103mm x 241mm x 49.5mm

Analog Input
1

RS232 Serial Port
1.
