R911324883 (CSH01.1C-PB-EN2-EN1-NNN-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-EN1-NNN-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth motion control unit with MPN R911324883 (CSH01.1C-PB-EN2-EN1-NNN-NN-S-NN-FW) is designed for industrial automation applications requiring precise control and flexible I/O configuration. It features support for EnDat 2.1, 1 Vpp, or TTL encoders under Option 1 and HSF/RSF encoders as Option 2. The unit offers 11 digital inputs, one analog input, four digital outputs, and two analog outputs. It supports PROFIBUS master communication and a standard control panel. Key electrical parameters include a maximum pulse width of 100 ms at 24 VDC and a minimum SERCOS cycle duration of 250 μs. Power output is rated at 7.5 kW. Firmware is provided separately.

Technical Specifications

Product Type
Advanced industrial automation products

Functioning Environment
Specified in user manual

Option 1 Encoder
EnDat 2.1

Digital Inputs
11

Velocity Control Time Range
125-250 milliseconds

Current Control Time Range
62.5-125 milliseconds

Position Control Time Range
250-500 milliseconds

Control Section Durability
Enduring

Option 2 Encoder
HSF/RSF encoder

Analog Input
Single

Power Supply
24-volt DC

Maximum Pulse Width
100 milliseconds

Power
7.5 kW

Digital Outputs
4

Analog Outputs
2

Relay Contact
Single

Switching Frequency
2-16 Hz

Control Panel
Conventional

Minimum SERCOS Cycle Duration
250 microseconds

Communication
PROFIBUS master

Wire Type
Stranded wire

Wire Diameter
0.75 to 1.50 mm.
