R911324884 (CSH01.1C-S3-ENS-EN1-NNN-L1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-S3-ENS-EN1-NNN-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 45 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911324884 (CSH01.1C-S3-ENS-EN1-NNN-L1-S-NN-FW) is a control section from the CSH series designed for use in Bosch Rexroth drive controllers. It features a compact profile measuring 49.5 mm wide, 103 mm long, and 241 mm high, enabling integration in space-constrained environments. The unit supports two analog outputs and provides master communication via the SERCOS III interface for high-speed device connectivity. Supported encoder options include Indradyn, Hiperface, 1 Vpp, and TTL. Cooling is managed by natural convection, with forced ventilation recommended only for close-wall configurations. Operation is specified for ambient temperatures from 0 to 40°C. Ports are available for both analog and digital connections. Humidity levels above 90% require protection against condensation.

Technical Specifications

Product Type
Control Section

Product Family
CSH Family

Width
49.5mm

Length
103mm

Height
241mm

Cooling System
Natural Convection (No Additional Fan Required)

Interface
SERCOS III

Analog/Digital Input/Output Port
Present

Optimum Ambient Temperature
0 to 40 degrees Celsius

Common Misspellings

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the CSH01.1C-S3-ENS-EN1-NNN-L1-S-NN-FW.

Exchange

Want to sell your CSH01.1C-S3-ENS-EN1-NNN-L1-S-NN-FW?
