R911325788 (CSH01.1C-ET-EN2-NNN-NNN-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-ET-EN2-NNN-NNN-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911325788 (CSH01.1C-ET-EN2-NNN-NNN-S1-S-NN-FW) is a modular CSH control section engineered for integration with IndraDyn controllers. It provides a MultiEthernet master communication interface, an integrated RS-232 serial port, and accommodates three optional plug-in modules along with a safety technology I/O option. The unit includes primary encoder support via EnDat 2.1, 1 Vpp, or TTL interfaces. It supports two analog outputs, variable control cycle times from 62.5 to 500 µs, and multiple switching frequencies for adaptable single-axis position control. Physical dimensions are 241 x 49.5 x 103 mm, with operation at 24 VDC and a typical power consumption of 7.5 W. Firmware supporting various feature sets is ordered separately.

Technical Specifications

Firmware
Needs to be ordered separately

Architecture
Modular

Plug-In Module
1 Encoder with EnDat 2.1 interface

Safety Option
Safety technology I/O

Control Panel Compatibility
Standard control panel only

Master Communication Interface
MultiEthernet

Serial Port
Integrated RS-232

Minimum SERCOS Cycle Time
250 microseconds

Switching Frequencies Supported
2, 4, 8, 12 and 16 kilohertz

Applications
Single-axis position control

Dimensions
241 x 49.5 x 103 millimeters

Supply Voltage
24 Volts DC

Power Consumption
7.5 Watts
