R911327301 (CSH01.1C-ET-EN2-NNN-NNN-L1-S-NN-FW)

Name: R911327301 (CSH01.1C-ET-EN2-NNN-NNN-L1-S-NN-FW)
Brand: Indramat Controls
SKU: CSH01.1C-ET-EN2-NNN-NNN-L1-S-NN-FW
Price: 484.00 USD
Availability: InStock

CSH Advanced Controllers

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911327301 (CSH01.1C-ET-EN2-NNN-NNN-L1-S-NN-FW) is a digital control section used in IndraDyn drive controllers. It is equipped with safety logic to inhibit unintentional motor startups after faults and permits secure deactivation of specific machine or plant zones. The unit supports up to three plug-in modules, which include an encoder module with EnDat 2.1 interface and options for additional modules. It provides two analog outputs, supports MultiEthernet for master communication, and is compatible with EnDat 2.1, 1 Vpp, or TTL primary encoder options. The device features a standard control panel with a single-line display and a four-button keypad for command input and system diagnostics. Installation and handling require qualified technical personnel due to inherent safety risks.
