R911327996 (CSH01.1C-PB-EN2-MA1-MD2-NN-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The R911327996 (CSH01.1C-PB-EN2-MA1-MD2-NN-S-NN-FW) is a control section module within the IndraDrive platform, designed for single-axis automation tasks. It is equipped with optional modules for encoder interfacing (EnDat 2.1, 5V), analog I/O (four channels, ±10V range, with two analog outputs), and digital I/O (16 digital inputs/outputs with SSI encoder interface). Master communication is provided via PROFIBUS. A standard control panel is required and must be connected before operation. The module operates at 24 VDC with a typical power consumption of 7.5 W. Installation must be performed using Bosch-approved components.

Technical Specifications

Primary Usage
IndraDrive Controllers

Structure
Modular

Encoder Module
EnDat 2.1 module (5 Volts)

Physical Interface
15-pin D-sub female interface

In-built Analog Interface
Included

Analog I/O Extension Module
±10 Volts, 4 separate analog channels

Safety Module
Not Included

Control Panel Type
Standard (Non hot-swappable)

Master Communication Interface
Profibus

Suitability
Single-axis Applications

Power Consumption
Approx. 7.5 Watts

Operating Voltage
24 Volts DC

Mounting
On Power Section

Installation
Professional Required

Approved Accessories
From Bosch

Common Misspellings

Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
product repair We offer a repair service for the CSH01.1C-PB-EN2-MA1-MD2-NN-S-NN-FW.
