R911328175 (CSH01.1C-PB-EN2-EN2-MEM-S1-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-EN2-MEM-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911328175 (CSH01.1C-PB-EN2-EN2-MEM-S1-S-NN-FW) is a Bosch Rexroth control section incorporating 4 digital outputs, 2 analog outputs, and an analog input. It features S2 safety technology, an encoder emulator (option 3), and supports 7 to 11 digital inputs. The unit provides Profibus communication and is compatible with EnDat 2.1, 1 Vpp, and TTL encoders. Technical parameters include a 7.5 W power consumption, 4 A inrush current, PWM frequency adjustable from 2 kHz to 16 kHz, and pulse width of 100 ms. Control current ranges from 62.5 to 125 μs, speed control response from 125 to 250 μs, and position control from 250 to 500 μs. Product documentation should be consulted for proper installation and operation.

Technical Specifications

Digital Outputs
4

Analog Inputs
1

Encoder Options
EnDat2.1

PWM Frequency
2-16 kHz

Power Consumption
7.5 W

Pulse Width
100 milliseconds

Inrush Current
4 A

Applications
Printing equipment, Food packaging

Digital Inputs
7-11

Control Current
62.5-125 microseconds

Speed Control
125-250 microseconds

Position Control
250-500 microseconds

Analog Outputs
2

Safety Technology
S2

Availability
In Stock
