R911328486 (CSH01.3C-ET-ENS-MEM-CCD-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-ET-ENS-MEM-CCD-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 5 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911328486 (CSH01.3C-ET-ENS-MEM-CCD-S2-S-NN-FW) is a single-axis control section from the CSH series designed for precise automation tasks in machinery such as packaging, printing, and machine tools. It incorporates a Multi-Ethernet interface supporting SERCOS III, ProfiNet, and EtherCAT, compliant with IEEE 802.3. The unit operates at selectable switching frequencies of 2kHz, 4kHz, 8kHz, 12kHz, and 16kHz, and utilizes screw terminal blocks and spring terminals to provide vibration-resistant connections. The control section features two analog outputs and supports master communication via MultiEthernet. It includes a standard encoder evaluation interface compatible with IndraDyn, Hiperface, 1 Vpp, and TTL encoders. Compliance with IEC 61800-3 category C3 classifies it for industrial environments, and additional radio interference suppression may be necessary for operation in public low-voltage networks.

Technical Specifications

Ethernet Field Bus Systems
SERCOS III, ProfiNet, EtherCAT

Communication Standard
IEEE 802.3

Display Elements
Data transmission and network connectivity

Switching Frequencies
2 kHz, 4 kHz, 8 kHz, 12 kHz, and 16 kHz

Firmware Use
Permitted (Ordered Separately)

Connection
Screw terminal blocks and spring terminals

Category
C3 (IEC 61800‑3)

Encoder Interface
Standard Encoder Evaluation
