R911328607 (CSH01.1C-SE-ENS-NNN-MEM-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-ENS-NNN-MEM-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911328607 (CSH01.1C-SE-ENS-NNN-MEM-L2-S-NN-FW) is a control section designed for automation applications requiring precise and rapid processing. It features a control panel with 1 watt power consumption and two slots, including X10 for an encoder emulator and X4 for an encoder. The unit supports one analog input, two analog outputs, a RS232 serial interface, and four digital outputs, as well as seven to eleven digital inputs. Current control operates within 62.5 to 125 microseconds, speed control within 125 to 250 microseconds, and position control within 250 to 500 microseconds. Master communication is provided via a SERCOS interface, and supported encoder options are IndraDyn, Hiperface, 1 Vpp, and TTL. The unit measures 103 mm in width, 241 mm in height, and 49.5 mm in depth. This model is not compatible with residential low-voltage distribution mains.

Technical Specifications

Control panel power consumption
1 watt

X8 slot status
empty

X10 slot status
encoder emulator

Analog input
One

RS232 serial interface
One

Digital outputs
Four

Current control durations
62.5 to 125 microseconds

Position control durations
250 to 500 microseconds

Speed control durations
125 to 250 microseconds

Control section power consumption
7.5 watts

Number of digital inputs
7 to 11

Handling requirement
Skilled personnel

Touch probes among digital inputs
Two

Width-modulation model inrush current
Four amperes

Included communication module
Master SERCOS interface

X4 slot encoder
Hiperface/1 Vpp/TTL

Compatibility with residential low-voltage mains
Incompatible

Product dimensions (width x height x depth)
103 mm x 241 mm x 49.5 mm

SERCOS cycle time
250 ms.
