R911328824 (CSH01.1C-CO-ENS-EN2-NNN-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-CO-ENS-EN2-NNN-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911328824 (CSH01.1C-CO-ENS-EN2-NNN-S2-S-NN-FW) is a Bosch Rexroth CSH01.1C control section designed for single-axis applications and vertical installation. It includes a memory card slot (X7 connector) and is equipped with integrated safety technology. Compatible with corresponding Rexroth drive controllers, this unit supports two analog outputs, CANopen/DeviceNet master communication, and offers encoder options including Indradyn, Hiperface, 1 Vpp, and TTL. The module features four digital I/O, five selectable switching frequencies, and internal protection against supply voltage polarity reversal via a fitted diode. Its physical dimensions are 241 x 103 x 49.5 mm. Not compatible with VCP series comfort panels; firmware is required and must be ordered separately.

Technical Specifications

Configuration Slots
1

Installation Orientation
Vertical

Connector Type
X7

Usage
Drive Controller Requirement

Protection
Protective Diode Inside Power Supply Unit

Digital Inputs/Outputs
4

Option Slots
4

Line Code
01

Switching Frequencies
5

Minimum SERCOS Cycle Time
250μs

Analog Outputs
2

Digital inputs (alternatively used as analog inputs)
I6, I7

Dimensions
241 x 103 x 49.5mm

Firmware
Must be bought separately

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the CSH01.1C-CO-ENS-EN2-NNN-S2-S-NN-FW.

Exchange

Want to sell your CSH01.1C-CO-ENS-EN2-NNN-S2-S-NN-FW?
