R911328827 (CSH01.3C-NN-ENS-NNN-CCD-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-NN-ENS-NNN-CCD-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911328827 (CSH01.3C-NN-ENS-NNN-CCD-L2-S-NN-FW) is a Rexroth Indramat servo drive control module designed for integration within modular drive systems. It includes two analog outputs and supports encoder feedback formats such as IndraDyn, Hiperface, 1 Vpp, and TTL. The unit does not come equipped with master communication capability. Operating at a power consumption of 8.5 watts and a maximum leakage current of 3.5 mA, it is recommended to ground the device for operational safety. The module is specified for use at altitudes up to 1000 meters and in ambient temperatures from 0°C to 40°C. Firmware is not supplied and must be sourced separately.

Technical Specifications

Operational Efficiency
95%

Requirement
Connection to power supply unit

Supported Encoder Designs
Hiperface and Indradyn

Maximum Installation Height
1000 meters above sea level

Permissible Ambient Temperature
0-40 degrees Celsius

Firmware
Not included, can be ordered separately

Energy Consumption
8.5 watts

Leakage Current
3.5 milliamperes

Safety Requirement
Proper grounding before operation
