R911329068 (CSH01.1C-PB-EN1-NNN-NNN-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN1-NNN-NNN-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911329068 (MPN: CSH01.1C-PB-EN1-NNN-NNN-S2-S-NN-FW) is a drive controller equipped with a CSH01.1 control section designed for high-performance, single-axis motion control applications. It features 4 digital outputs, 2 analog outputs, one analog input, and supports 7 to 11 digital inputs. The control section allows for adjustable PWM frequency from 2 kHz to 16 kHz. Control loop cycle times are 62.5–125 microseconds for current, 125–250 microseconds for speed, and 250–500 microseconds for position. The unit incorporates PROFIBUS master communication and a primary encoder interface option for HSF/RSF. Power consumption is specified at 7.5 W, and pulse width duration is 100 ms. Typical applications include industrial automation systems such as printing and food packaging machinery. Firmware must be sourced separately.

Technical Specifications

Digital Outputs
4

Analog Inputs
1

Use
Single-Axis Drive and Control Applications

Variable Drive Power
Yes

Interfaces
Multiple

PWM Frequency
2 KHz - 16 KHz (Multiples of 2 KHz)

Firmware Requirement
Separate Purchase

Digital Inputs
7 - 11

Control Current
62.5 - 125 microseconds

Speed Control
125 - 250 microseconds

Position Control
250 - 500 microseconds

Communication
PROFIBUS Master

Analog Outputs
2

Power Requirement
7.5 W

Pulse Width
100 milliseconds

Safety Technology
S2 with HSF/RSF Encoder

Seller
Indramat USA

Delivery
Worldwide.
